PRIMO EU

PT-40-NFA Technical Specifications

Cooling Type	Peltier Thermoelectric
Capacity (liters / cubic feet)	38 / 1.34
Dimensions HxWxD	21.89 x 17.36 x 17(in) 566 x 441 x 432 (mm)
Compartment Type	Cellar
Energy Class	G
Energy Efficiency Index	208.4
Climate Class	N (16°C to 32°C)
Operating Temperature	8°C–14°C
Door Options	Black Frame Glass Door
Watts (W)	60W
Voltage (V)	110V / 60Hz or 220V / 50Hz
Amps (A)	0.5-0.9A
Energy Consumption (kWh/24h)**	0.26 kWh/24h**
Net Weight (lbs / kg)	32.63±2lbs / 14.8±1kgs
Noise Level (dB)	26 dB (Noisless)
Certification	CCC / CE / CB / CETL / CSA and ROHS compliant. Our production plants are ISO9001 and ISO14001 certified

*Measured to door handle
** Average energy consumption per 24 hours, at 25°C (77°F) ambient temperature and 7°C (44.6°F) cooling temperature, in compliance with EN ISO 7371

Adjustable transparent door racks for high visibility
Removable shelving for easy cleaning
Thermal insulation manufactured with eco-friendly cyclopentane
Fully automatic defrost and easily adjustable thermostat
Strong universal convertible door hinges – left/right
All-round magnetic seals to keep the door perfectly shut
Noiseless Technology
Internal LED lighting
Low energy consumption
Advanced Peltier cooling technologies
Glass door without lock (Optional)
High impact exterior finish

Ventilation Specifications

A minimum opening of 31 in2 (200 cm2) for Intake, Shelf Cutout and Exhaust is required for proper ventilation.

Primo User/Instruction Manual	PT-27NF Cut Sheet
Primo Product Brochure	PT-27NF Product Information Sheet
Limited Warranty	PT-27NF EEI Label

Peltier Cooling

Harness the power of Peltier thermoelectric cooling technologies to redefine the minibar experience in hotels, offering an innovative cooling solution that is not only efficient but also remarkably quiet. This cutting-edge technology utilizes solid-state components to provide reliable temperature control without the noise and vibration associated with traditional cooling methods, ensuring that your guests enjoy a peaceful and comfortable environment.

3 in 1Thermostat

Perfect blend of convenience and innovation with our fully adjustable thermostat, designed to elevate your space while keeping your beverages at the ideal temperature. This cutting-edge minibar features an automatic defrost function that ensures hassle-free maintenance, allowing you to focus on what matters most. The built-in LED light not only adds a touch of sophistication but also enhances visibility, making it easy to find your favorite drinks even in low light.

2 in 1 Lock

Experience unparalleled convenience with our innovative minibar lock, designed for ultimate flexibility. With just a simple flip of a plastic cover, you can seamlessly deactivate the lock, offering you quick access to your refreshments whenever you need them. This thoughtful feature enhances security while providing the freedom to enjoy your drinks without hassle, making it the perfect addition to your hotel minibar.

Evaporator Plate

Experience the pinnacle of cooling efficiency with our over-engineered aluminum evaporator plate, designed specifically for Peltier cooling systems. This meticulously crafted component maximizes heat transfer capabilities, ensuring that your beverages are chilled to perfection while minimizing energy consumption. The evaporator plate not only enhances thermal performance but also contributes to a quieter operation, creating an inviting ambiance for any setting.
